2010 Yamaha Raptor 90
Request a Quote Financing Calculator Request a Brochure Financing Form
Request a Quote Financing Calculator Request a Brochure Financing Form
  • OEM Overview
  • Specifications
  • Compare Models
  • Current Promotions

Overview

 Print Brochure

For kids 12 years and older, the Raptor 90 is an excellent machine to start learning on.


Powered by a reliable 88cc air-cooled 4-stroke engine coupled to a fully automatic CVT transmission, the Raptor 90 is not only easy to use, but can accommodate various levels of riding ability. And there's an adjustable rev limiter to help you manage their learning curve.


Quiet and Reliable 4-Stroke Engine: Powered by an 88cc forced air cooled 4-stroke engine for years of clean, quiet and reliable operation.


Electric Start: Easy, push-button electric start in any gear for greater convenience.


Adjustable RPM Limiter: Adjustable RPM limiter allows a parent or adult supervisor to match the engine's power output to the rider's skill level.


Fully Automatic CVT Transmission: Fully automatic makes it easier to learn, while the CVT helps ensure engine power is optimized for a wide variety of riding conditions. This allows the entry-level rider focus on the trail by eliminating a hand-operated clutch.


Double Wishbone Front Suspension: With 4.4"" is suspension travel in the front and pre-load adjustable shocks, the little Raptor 90 is capable and comfortable.


Swingarm Rear Suspension: The lightweight rear swingarm suspension also has a pre-loead adjustable shock, and is designed to help the Raptor 90 stay flat in a corner, while maintaining predictable handling.


Hydraulic Rear Disc Brake: Light in weight, a hydraulic disc brake helps provide consistent stopping power, in a variety of riding conditions.

    Engine Specifications
    • Engine: 4-stroke, air-cooled, single
    • Displacement: 88 cc
    • Bore and Stroke: 47mm x 51mm
    • Compression Ratio: 10.2 : 1
    • Carburetion: 22mm SVR
    • Ignition: CDI
    • Starting: electric with auxillary kick
    • Oil Capacity: 0.8 litres
    • Transmission: fully automatic CVT
    • Final Drive: 2WD; chain
    Chassis Specifications
    • Suspension (Front): double wishbone with 4.4" of travel and pre-load adjustable shocks
    • Suspension (Rear): swing-arm with 3/3" of travel and a pre-load adjustable shock
    • Brakes (Front): dual sealed drums
    • Brakes (Rear): single hydraulic disc
    • Tires (Front): low profile Maxxis; AT18x7-8
    • Tires (Rear): low profile Maxxis; AT18x9-8
    Dimensions
    • Length: 1,490mm (58.7")
    • Width: 885mm (34.8")
    • Height: 910mm (35.8")
    • Wheelbase: 1,010mm (39.8")
    • Ground Clearance: 100mm (3.9")
    • Seat Height: 654mm (25.7")
    • Dry Weight: 116 kg (254 lb)
    • Fuel Capacity: 4.8 litres
    • Colour(s): Racing Blue, White
    Additional Features
    • Lightweight and super-reliable chain drive provides an excellent balance between performance and reliability.
    • Rugged muffler equipped with a USFS-approved spark arrestor for quiet operation.
    • Wide cushy seat and full-size handlebars ensure supurb, all-day comfort and minimize fatigue for even the biggest riders.
    • Fully sealed front drum brakes keep out water and debris, providing strong, reliable stopping power.
    • Handlebar-mounted parking brake.
    • Styled after the best selling Raptor 700R
    • Emergency kick starter with lever under the seat, for reliable starting if the battery loses its charge
    • Two separate types of engine performance limiters: 1. A throttle opening limit screw on the throttle lever housing. 2. A bypass plate on CDI unit for limiting maximum engine rpm.
    • Raptor style front and rear grab bars
    • Drive sprocket and chain guard
    • Rear disc brake guard
    • Easy to use handlebar mounted parking brake

    Specifications

    Engine
    Engine Type 4-stroke, single
    Displacement 88 cc
    Bore x Stroke 47 x 51mm
    Engine Cooling Air-cooled
    Starting System Ignition: CDI; Starting: electric with auxillary kick
    Chassis
    Front Suspension double wishbone with 4.4" of travel and pre-load adjustable shocks
    Front Travel 4.4 in.
    Front Brake Type dual sealed drums
    Front Tires low profile Maxxis; AT18x7-8
    Rear Suspension swing-arm with 3/3" of travel and a pre-load adjustable shock
    Rear Travel 3.3 in.
    Rear Brake Type single hydraulic disc
    Rear Tires low profile Maxxis; AT18x9-8
    Dimensions/Capacities
    Dry Weight 116 kg (254 lbs.)
    Fuel Capacity 4.8 l (1.3 gal)
    Ground Clearance 100mm (3.9")
    Machine Dimensions (LxWxH) 1,490 mm (58.7 in.) x 885 mm (34.8 in.) x 910 mm (35.8 in.)
    Wheelbase 1,010mm (39.8")
    Drive Train
    Final Drive 2WD; chain
    Transmission fully automatic CVT
    General
    Colors Racing Blue, White
    Warranty 6 Month (Limited Factory Warranty)

    Compare Models

    		 Print








    Year 2010
    Manufacturer Yamaha
    Model Raptor 90
    Style Sport
    MSRP* $3,549.00
    Chassis
    Front Suspension double wishbone with 4.4" of travel and pre-load adjustable shocks
    Front Travel 4.4 in.
    Front Brake Type dual sealed drums
    Front Tires low profile Maxxis; AT18x7-8
    Rear Suspension swing-arm with 3/3" of travel and a pre-load adjustable shock
    Rear Travel 3.3 in.
    Rear Brake Type single hydraulic disc
    Rear Tires low profile Maxxis; AT18x9-8
    Frame
    Dimensions/Capacities
    Dry Weight 116 kg (254 lbs.)
    Front Rack Capacity
    Rear Rack Capacity
    Towing Capacity
    Fuel Capacity 4.8 l (1.3 gal)
    Ground Clearance 100mm (3.9")
    Machine Dimensions (LxWxH) 1,490 mm (58.7 in.) x 885 mm (34.8 in.) x 910 mm (35.8 in.)
    Wheelbase 1,010mm (39.8")
    Drive Train
    Drive Train
    Final Drive 2WD; chain
    Transmission fully automatic CVT
    Engine
    Engine Type 4-stroke, single
    Displacement 88 cc
    Bore x Stroke 47 x 51mm
    Cylinders
    Engine Cooling Air-cooled
    Fuel System
    Starting System Ignition: CDI; Starting: electric with auxillary kick
    Alternator
    General
    Speedometer
    Tachometer
    Odometer
    Lighting
    Colors Racing Blue, White
    Warranty 6 Month (Limited Factory Warranty)
